Farenhyt  IDP-ZONE Addressable Zone Interface Module

The Farenhyt IDP-ZONE Addressable Zone Interface Module enables seamless integration between two-wire conventional smoke detectors and Farenhyt Series Addressable Fire Alarm Control Panels (FACPs). This intelligent module allows system designers to retrofit existing conventional systems, expanding functionality without replacing all field devices—saving both time and cost.

Where It Can Be Used

The Farenhyt IDP-ZONE Module is ideal for retrofitting and upgrading older buildings or facilities that already use conventional detectors. It is widely used in:

• Commercial and office buildings
• Educational institutions and universities
• Hospitals and healthcare facilities
• Industrial plants and manufacturing units
• Hotels, shopping malls, and government facilities

By supporting both Style B (Class B) and Style D (Class A) wiring, it provides installation flexibility for diverse fire protection environments.

IDP-ZONE

The Farenhyt IDP-ZONE is an intelligent two-wire interface module that allows a Farenhyt Fire Alarm Control Panel (FACP) to monitor and control a full zone of conventional two-wire smoke detectors. It reports the status of the connected zone—normal, open, or alarm—directly to the control panel.

Each IDP-ZONE module supervises detector wiring and the external power supply connection, ensuring reliable communication and system integrity. It mounts easily in a standard 4-inch electrical box and includes LED indicators for system status, simplifying installation and maintenance.

Compatible with Farenhyt control panels such as IFP-2100, IFP-2000, IFP-1000, IFP-300, IFP-100, IFP-75, and IFP-50, the IDP-ZONE enhances system scalability and supports efficient modernization of legacy systems.

Advantages

• Converts a conventional two-wire loop into an addressable SLC loop
• Enables easy integration of existing conventional detectors
• Reduces upgrade costs during retrofit projects
• Fully supervised for reliable operation
• Supports Style B (Class B) and Style D (Class A) wiring configurations
• Panel-controlled LED indicates normal (green) and alarm (red) states
• Rotary address switches for simple configuration
• SEMS screws for faster wiring connections
• UL, CSFM, and MEA listed for proven compliance and safety

Areas We Serve

Fire Projects Pvt. Ltd. supplies and installs Farenhyt IDP-ZONE Modules across Gujarat, including Ahmedabad, Vadodara, Halol, Sanand, Vapi, Ankleshwar, and Dahej.
We serve sectors such as:

• Industrial and petrochemical facilities
• Hospitals and healthcare centers
• Commercial complexes and IT parks
• Educational and government institutions

Why Choose Fire Projects Pvt. Ltd.?

At Fire Projects Pvt. Ltd., we specialize in delivering certified Farenhyt fire detection and alarm systems for modern, compliant, and reliable fire safety. From consultation and design to installation and after-sales support, our experienced team ensures that every system is installed to perfection and meets international fire protection standards.

Contact Us: +91 98244 42333| Email: info@fireprojects.co.in|Website: www.fireprojects.co.in
